MVTec HALCON 13

NEW Version of MVTec’s comprehensive image processing software for machine vision with an integrated development environment (IDE) that is used worldwide.

  • Outstanding performance
  • Wide range of camera support incl 3D

Downloads

Contact us for pricing and availability – sales@multipix.com +44 (0)1730 233332

HALCON 13 brings a whole range of new and improved technologies. This version provides significantly increased performance for shaped-based matching. In addition, damaged, occluded, or incomplete bar codes, as well as deformed data codes can now be recognised and read more robustly. Texture inspection made easy is certainly a highlight with HALCON 13. This version offers an enhanced, deep learning based optical character recognition (OCR), as well as the automatic, robust identification of dot print fonts.

Here’s a glance at some of the features HALCON 13 has to offer…

SPEEDUPS

HALCON 13 brings a giant leap in performance for shape-based matching, one of HALCON’s core technologies. For example, speedups of more than 300% can be achieved on machines with AVX2-compatible processors, when searching byte images with a small number of pyramid levels. But not only that, HALCON 13 also offers significant speedups for all related technologies, i.e., shape-based 3D matching, local and perspective deformable matching, and component-based matching.

TEXTURE INSPECTION

Texture inspection can be a challenging task because textures often have very different characteristics like scale or bright­ness. Therefore, setting up a texture inspection system is often tricky. HALCON 13 offers an easy-to-use texture inspection, which is configured by simply passing some training images. The algorithm automatically adjusts the necessary parameters based on training images that show flawless texture. The trained texture inspection model can then be used to detect potential texture defects.

3D MATCHING & RECONSTRUCTION

In HALCON 13, surface-based 3D matching has been improved to be more robust when dealing with flat surfaces. This improvement particularly supports applications like picking of boxes. HALCON 13 also offers a new method to reconstruct 3D objects from multiple cameras with high quality. This new method uses the information of all camera views at once leading to more robust results than provided by common stereo reconstruction methods.

MAJOR IMPROVEMENTS IN IDENTIFICATION PROPERTIES

HALCON 13 now offer deep-learning-based OCR for the first time: HALCON now contains a new OCR classifier and comes with a number of pre-trainedfonts based on deep learning technology. With these, it is possible to achieve higher reading rates than with all previous classification methods. Furthermore, the automatic text reader in HALCON 13 is faster and now also supports reading of dot print characters.

HALCON 13 also reads bar codes even if large parts of the code are either defective or not visible at all. Additionally, the QR code reader has been improved and is now much more robust against common challenges like blur or distortion.

DEBUGGING OF HDEVENGINE APPLICATIONS

HDevEngine applications can now be de­bugged directly within HDevelop. HDevEngine allows de­velopers to execute HDevelop code within their C# or C++ application. By attaching HDevelop to this application, the machine vision part can now be debugged using HDevelop. This debugging enables the developer to inspect call stack and variable values while executing procedures step by step, making error tracking a lot easier.You can even connect HDevelop to an HDevEngine application running on a different computer for remote debugging. For example, debugging a machine on the factory floor can be done directly from the office with this connection. This functionality is also extremely useful for debugging HALCON Embedded devices such as smart cameras.

Why not check out MVTec’s MERLIC 3 Image Processing Software?

MERLIC is an all-in-one software product for quickly building machine vision applications without programming. Find out more…

Learn more...

MVTec’s HALCON Now Available for ARM-Based Platforms

HALCON 13.0.1 now available for ARM-based Platforms HALCON will now be available as a standard download for ARM-based platforms running Linux operating systems. This version will provide a straightforward way to use HALCON’s powerful functions on the widely distributed ARM processing technology, thereby significantly expanding the range of devices on which customers can deploy their machine... Read more »

Learn more
mpx

Enhancements of 3D Matching and 3D Reconstruction with HALCON 13

In HALCON 13, surface-based 3D matching has been improved to be more robust when dealing with flat surfaces. The new matching algorithm now analyses edges in both the object model and the 3D scene. This means that ambiguities from flat surfaces can now be solved using edge data. For example, a flat object will have... Read more »
